Product: MAX4-F WATERCOOLED - Submersible electric pump with 100mm diameter for clean water - MAX 4 SUBMERSIBLE ANTI-SAND ELECTRIC PUMPS WITH 100 DIAM.
click to zoom the image
|
MAX 4-F Water Cooled Pump - Single-phase 1x230Vac - Three-phase 3x400Vac
Suitable for pumping liquids with max. 450 g/m3 solid content
Resists in dry operation (without water)
Ecological - Watercooled motor Nomenclature: MAX4 series F Watercooled
Use: Clear water lifting
Power supply: 230Vac single-phase / 400Vac three-phase
Maximum flow: 175 liters per minute
Maximum height (single phase): 85 meters (MAX4 F16 + MXW43M)
Maximum height (three-phase): 303 meters (MAX4 F50 + MXW410)
Power used (single phase): from 0.75kW - 1.00Hp to 2.20kW - 3.00Hp
Power used (three-phase): from 0.75kW - 1.00Hp to 7.50kW - 10.00Hp
Max sand content: 450 grams/m3
Applications: Wells (minimum internal diameter 105mm, tanks)
Protection class: IP68
Supplied electric cable: 1.5 meters
|
|
|
Power |
Volts |
Flow rate |
Shipping |
VAT |
Order now! |
||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
kW |
Hp |
|
Q=l/min' |
0 | 80 |
100 |
125 |
175 |
||||
|
Q=m3/h |
0 | 4,8 |
6 |
7,5 |
10,5 |
||||||
|
MAX4F05 + MXW41 TRIFASE |
0,75 |
1,00 |
3x400 |
H=ml |
28 | 25 |
20 |
12 |
2 |
Sconto 20 % |
|
|
|
MAX4F05 + MXW41M MONOFASE |
0,75 |
1,00 |
1x230 |
H=ml |
28 | 25 |
20 |
12 |
2 |
Sconto 20 % |
|
|
|
MAX4F08 + MXW415 TRIFASE |
1,10 |
1,50 |
3x400 |
H=ml |
43 | 38 |
30 |
19 |
4 |
Sconto 20 % |
|
|
|
MAX4F08+MXW415M MONOFASE |
1,10 |
1,50 |
1x230 |
H=ml |
43 | 38 |
30 |
19 |
4 |
Sconto 20 % |
|
|
|
MAX4F11 + MXW42 TRIFASE |
1,50 |
2,00 |
3x400 |
H=ml |
57 | 51 |
40 |
25 |
5 |
Sconto 20 % |
|
|
|
MAX4F11 + MXW42M MONOFASE |
1,50 |
2,00 |
1x230 |
H=ml |
57 | 51 |
40 |
25 |
5 |
Sconto 20 % |
|
|
|
MAX4F16 + MXW43 TRIFASE |
2,20 |
3,00 |
3x400 |
H=ml |
85 | 76 |
60 |
37 |
7 |
Sconto 20 % |
|
|
|
MAX4F16 + MXW43M MONOFASE |
2,20 |
3,00 |
1x230 |
H=ml |
85 | 76 |
60 |
37 |
7 |
Sconto 20 % |
|
|
|
MAX4F22 + MXW44 TRIFASE |
3,00 |
4,00 |
3x400 |
H=ml |
114 | 101 |
80 |
50 |
10 |
Sconto 20 % |
|
|
|
MAX4F30 + MXW455 TRIFASE |
4,00 |
5,50 |
3x400 |
H=ml |
170 | 152 |
121 |
75 |
14 |
Sconto 20 % |
|
|
|
MAX4F40 + MXW475 TRIFASE |
5,50 |
7,50 |
3x400 |
H=ml |
225 | 200 |
159 |
99 |
19 |
Sconto 20 % |
|
|
|
MAX4F50 + MXW410 TRIFASE |
7,50 |
10,00 |
3x400 |
H=ml |
303 | 270 |
215 |
133 |
26 |
Sconto 20 % |
|
|
The supply does NOT include: the electrical control panel and the electric cable
Confidential agreements for large quantities
DESCRIPTION
Submersible electric pumps with reduced dimensions (diameter: 100mm); They are suitable inside tanks (preferably with cooling jacket) and in wells, with clean water. The MAX4 submersible pumps is uncoupled. The shipping takes place in two pieces: motor and pump.
MAIN FUNCTIONS
Resistance to pumping water with sand (max 450g/cubic meter).
MAX4 submersible pumps require an electrical control panel equipped with a switch, a condenser and thermal protection.
MATERIALS
TECHNICAL FEATURES
Water temperature range: from +5 °C to +40 °C
